Extreme Networks AP510C-FCC
High Capacity, High-Efficiency Wi-Fi 6 Indoor External Antenna Access Point

Security

The AP AP510C/CX delivers the highest level of security services, beginning with support for the latest Wi-Fi Alliance WPA3 security certifications. Additionally, the AP AP510C/CX supports a stateful L2-L7 DPI firewall for context-based access security, Private Pre-Shared Key (PPSK) and much more.

Wi-Fi 6 Technology

Prior generations of 802.11n, 802.11ac wave 1 and 2, can be considered generational improvements with an emphasis on faster speed. 802.11ax technology instead enhances Wi-Fi efficiency as well as speed, taking Wi-Fi networks to an entirely new level. To learn more about 802.11ax, go to: Are you ready for 802.11ax?

Programmable Radios

Extreme launched the industry's first software defined 802.11ax access point supporting not only a dual 5 GHz capability but also two software programmable modes to optimally manage radios to provide the highest level of client performance. The AP AP510C/CX intelligent monitoring of the software- configurable radios enables network managers to configure network RF technology based on user environment and configure the access points in different modes as required.

Management Analytics

In conjunction with Extreme Management system, cloud or on-premises, the AP AP510C/CX provides a very rich set of data displayed via context driven widgets, representing historical data or a combination of historical and current data. This provides contextspecific granularity with perspective views for locations, network, APs, individual client devices, as well as policy roles. In each context, administrators can adjust dashboards make a widget library.

RF Monitoring

Network managers will appreciate a powerful choice of RF management for their Wi-Fi networks, with Adaptive RF management with AI/ML-like functionality. Adaptive RF algorithms provide intelligent selection of the best channels and transmit power for unimpaired dual 5 GHz operation. Load balancing, band steering and many other attributes of the RF can all be automated.

Integrated BLE and USB Port

To support both IoT and Guest Engagement services the AP AP510C/CX integrates Bluetooth to connect with IoT devices wireless to engage loyalty customers with Apple iBeacon. Enterprises can use API driven applications to send advertisements directly to shoppers, guests, and conference attendees. This makes it ideal for businesses to advertise their app download pages, captive portals, or site-specific information.

Radio Specifications

802.11a

• • 5.150–5.850 GHz Operating Frequency
• Orthogonal Frequency Division Multiplexing (OFDM) Modulation
• Rates (Mbps): 54, 48, 36, 24, 18, 12, 9, 6 w/ auto fallback

802.11b

• 2.4–2.5 GHz Operating Frequency
• Direct-Sequence Spread-Spectrum (DSSS) Modulation
• Rates (Mbps): 11, 5.5, 2, 1 w/ auto fallback

802.11g

• 2.4–2.5 GHz Operating Frequency
• Orthogonal Frequency Division Multiplexing (OFDM) Modulation
• Rates (Mbps): 54, 48, 36, 24, 18, 12, 9, 6 w/ auto fallback

802.11n

• 2.4–2.5 GHz & 5.150–5.850 GHz Operating Frequency
• 802.11n Modulation
• Rates (Mbps): MCS0 - MCS15 (6.5MBps - 300Mbps)
• 2x2 Multiple-In, Multiple-Out (MIMO) Radio
• HT20 High-Throughput (HT) Support (for both 2.4 GHz and 5 GHz)
• HT40 High-Throughput (HT) Support for 5 GHz
• A-MPDU and A-MSDU Frame Aggregation

802.11ac

• 2.4–2.5 GHz & 5.150–5.850 GHz Operating Frequency
• 802.11ax Modulation (1024-QAM)
• Dual-band OFDMA
• Rates (Mbps)
• 5G: HE0-HE11 (8 Mbps – 1200 Mbps).
• 2.4G: HE0-HE11 (8 Mbps – 574 Mbps).
• 2x2:2 Stream Multiple-In, Multiple-Out (MIMO) Radio
• HE20/HE40/HE80 support for 5 GHz
• HE20/HE40 support for 2.4 GHz
• DL SU-MIMO and MU-MIMO
• TxBF (Transmit Beamforming)

BLE 5 Radio Bluetooth® Low Energy (BLE) and IEEE® 802.15.4 compliant

Interfaces

• (1) Autosensing 10/100/1000 BASE-T Ethernet PoE (Power over Ethernet 802.3af) Port
• USB2.0, Type A 5V, 0.9A
• USB power <= 500 mA - 802.3af
• USB power > 500 mA - 802.3at

Power Options

• Power Draw: Typical: 9.98 W; Max: 11.28 W (w/o USB)
  Typical: 14.98 W; Max: 16.28 W (w/ USB)
• 802.3af Power over Ethernet (PoE) capable Gigabit Ethernet port (RJ-45 power input pins: Wires 4,5,7,8 or 1,2,3,6)
• Support 802.3af/802.3at Power over Ethernet injector

Power Specifications

• IEEE 802.3af PoE Power

Physical

• AP 305C: 5.2" x 5.2" x 1.5" (133mm x 133mm x 37mm)
• AP 305CX: 5.8" x 5.8" x 1.5" (147mm x 147mm x 39mm)
• AP 305C and AP 305CX: .9 lbs (.4kg)
• TPM Chip for added security

Antennas

AP 305C - Internal Antennas

• (2) Integrated single band, 2.4-2.5 GHz omnidirectional antennas
• (2) Integrated single band, 5.1-5.8 GHz omnidirectional antennas

AP 305CX - External Antennas

• (4) RP SMAs connectors

Mounting

• AP support 15/16 flush ceiling tile and is integrated to AP
• Wall Mount sold as an accessory
• Ceiling Tile Recessed 15/16" sold as an accessory
• Built-in slot for Kensington type locks

Environmental

• Operating: 0 to 40 °C, Storage: -40 to 70 °C
• Humidity: 10% to 95% (non-condensing)

Environmental Discharge

• +/-8 kV (contact discharge)/ +/-15 kV (Air Discharge)

Environmental COmpliance

• UL2043 - Plenum Rated

Regulatory Compliance

• IEC 62368/60950-1, EN 62368/60950-1, USA 62368/60950-1, AS/NZS 62368/60950.1, Intertek NTRL
• RoHS Directive 2011/65/EU

Radio Approvals

• FCC CFR 47 Part 15, Class B
• ICES-003, Class B
• FCC Subpart C 15.247
• FCC Subpart E 15.407
• RSS247
• AS/NZS4268 + CISPR32
• IEC/EN 60601-1-2,
• EN 62479
• EN 62311
• EN 50385
• EN 301 489-1
• EN 301 489-3
• EN 301 489-17
• EN 55032, (Class B)

Power Options

• EN 55011, (Group 1, Class B)
• EN 55024
• EN 60601-1-2
• EN 61000-3-2
• EN 61000-3-2
• EN 300 328
• EN 301 893
• EN 300 440
• EN 50581
